Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine

Product Categories

Shandong Gelon Lib Co., Ltd

Contact Now

Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine

Name: Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine
Brand: Gelon
Price: 28500 USD

Wholesale Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine from china suppliers

Brand Name : Gelon

Model Number : GN-DP200S

Certification : CE

Place of Origin : China

MOQ : 1/PCS

Price : USD 28500-31580/PCS

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10 PCS Per Month

Delivery Time : 4-6 week

Packaging Details : Wooden Carton

Working Voltage : AC220V 50/60Hz, 30mA

Stacking Layer Length : 200mm Max.

Fixed Travel Distance : 400mm

Travel Cycle : 1 - 9999 Cycles

Suggested Air Pressure : 0.25 - 0.55 MPa (40 - 80 Psi)

Net Weight : 70 Lbs

Compressed Sir Source : 0.5MPa~0.7MPa

Swing Stroke : 180mm

Contact Now

Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine

Stacking Layer Length: 200mm Max.
Fixed Travel Distance: 400mm
Travel Cycle: 1 - 9999 cycles
Air Pressure: 0.25 - 0.55 MPa

Instructions:
GN-DP200S is a semi-automatic stacking machine. It is an ideal tool for stacking multiple layers of
Cathode & anode electrode and separator for pouch cell.

Worki ng Voltage	AC220V 50/60Hz, 30mA
Stacking Layer Length	200mm Max.
Fixed Travel Distance	400mm
Travel Cycle	1 - 9999 cycles
Suggested Air Pressure	0.25 - 0.55 MPa (40 - 80 psi) (Air compressor is not included in the standard package)
Product Dimensions	Stacking Platform: 550mm(L) x 390mm(W) x 660mm(H) Control Box: 270mm(L) x 190mm(W) x 280mm(H)
Net Weight	70 lbs
Warranty	One Year limited warranty with lifetime support

Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine

We could supply one stop solution ( turn key project) for you.

1.Full set of lithium battery materials,including :

LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.

2.Full set of lithium battery equipments,for example:

mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

3.Full set of lithium battery technology.

we can design the laboratory and production line,according to customer's request.

Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine

Lithium Battery Lab Research Machine Pouch Cell Desktop Stacking Machine Images
