Lithium Battery Roll To Roll Electrode Calendaring Machine With Heating Function

Brand Name : Gelon

Model Number : GN-HR-330

Certification : CE

Place of Origin : China

MOQ : 1set

Price : USD 36,000-38,850 per set

Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram

Supply Ability : 10 sets per month

Delivery Time : 2 months

Packaging Details : wooden box package

Product name : Roll to Roll Electrode Calendaring Machine

Function : Electrode pressing and slitting

Equipment type : Semi automatic

Voltage : 380V

Width : 1-330mm

Speed : 0.8-5M/min

Calender Thickness : 0.01-2mm adjusted

Max Working Pressure : 80T

Contact Now

Lithium Battery Roll to Roll Electrode Calendaring Machine with Heating Function

GN-HR-330 Hydraulic Roller pressure machine is an Automatic Battery Electrode Rolling Press System with precision digital pressure control . The pressure can be adjusted easily by touch screen.

Name
Pressure Adjust Hydraulic Rolling Press Machine
Function
Calender battery electrode
Calender Model
Hydraulic press
Roller Size
210mmDia*300mmW, 9Cr3Mo materials
Calender Thickness
0.01-2mm adjusted
Effective Working Width
Max 300mm
Speed
2-8r/min
Efficiency
0.8-5M/min
Accuracy
0.003mm
Main Motor Power
0.75KW(380V 50Hz)
Heating
Without heating function 1.75KW*2
Max Working Pressure
80T
Rolling Press Machine Size
About L1870mm*W795mm*H1120mm
Weight
About 1200kg
Warranty
One-year limited warranty with all lifetime support

Lithium Battery Roll To Roll Electrode Calendaring Machine With Heating Function


Lithium Battery Roll To Roll Electrode Calendaring Machine With Heating Function

We also provide other full automatic production line .

Lithium Battery Roll To Roll Electrode Calendaring Machine With Heating FunctionLithium Battery Roll To Roll Electrode Calendaring Machine With Heating Function

Lithium Battery Roll To Roll Electrode Calendaring Machine With Heating Function
